Speed

Low speed

Top speed(Km/h)

45

Grade ability

20%

Charging time

6-8hours

Range(km) 40km/h

140

Model

JY7221-ZQR

EEC

L6e-BP

Overall dimensions(L*W*H)mm

2245*1290*1570

Wheel base(mm)

1500

Wheel track(mm)

1094/1094

Min.ground clearance(mm)

150

Curb weight(kg)

635(with battery)

Seating capacity

2

Motor type

AC motor

Kw Rated Power

3.5

Rated Voltage(V)

60

Battery

Maintenance-free lead acid battery

Speed

High speed

Top speed(Km/h)

80

Grade ability

20%

Charging time

6-8hours

Range(km) 40km/h

80~100

Model

JY7222-ZQR

EEC

L7e-CP

Overall dimensions(L*W*H)mm

2245*1290*1570

Wheel base(mm)

1500

Wheel track(mm)

1094/1094

Min.ground clearance(mm)

150

Curb weight(kg)

643(with battery)

Seating capacity

2

Motor type

AC motor

Kw Rated Power

7.5

Rated Voltage(V)

72

Battery

Maintenance-free lead acid battery

Speed

Low speed

Model

JY7221-ZQR

EEC

/

Overall dimensions(L*W*H)mm

2245*1290*1570

Wheel base(mm)

1500

Wheel track(mm)

1094/1094

Min.ground clearance(mm)

150

Curb weight(kg)

510(with battery)

Seating capacity

2

Motor type

AC motor

Kw Rated Power

3.5

Rated Voltage(V)

60

Battery

Maintenance-free ternary lithium battery

Battery capacity

10kw*h

Range(km) 40km/h

≥150

Speed

High speed

Model

JY7222-ZQR

EEC

L7E-CP

Overall dimensions(L*W*H)mm

2245*1290*1570

Wheel base(mm)

1500

Wheel track(mm)

1094/1094

Min.ground clearance(mm)

150

Curb weight(kg)

518(with battery)

Seating capacity

2

Motor type

AC motor

Kw Rated Power

7.5

Rated Voltage(V)

72

Battery

Maintenance-free ternary lithium battery

Battery capacity

10kw*h

Range(km) 40km/h

≥150

Speed

76km/h

Model

JY1320-ZLH

EEC

L7E-CU

Overall dimensions(L*W*H)mm (Car Body)

3150×1297×1685

Overall dimensions(L*W*H)mm(Van)（Outer size）

1350x1245x1000

Overall dimensions(L*W*H)mm(Van)（inner size）

1290*1200*960

Wheel base(mm)

2300

Wheel track(mm)

1094/1094

Min.ground clearance(mm)

150

Lithium battery：Curb weight Kg

639（with battery）/556（without battery）

Van Load(kg)

300

Seating capacity

2

Motor type

AC motor

Kw Rated Power

7.5

Rated Voltage(V)

72

Battery

Maintenance-free lithium battery

Battery capacity

10kw*h

Charger type

Car charger

Charging voltage(V)

220

Range(km) 40km/h

150

Speed

76km/h

Model

JY1320-ZLH

EEC

L7E-CU

Overall dimensions(L*W*H)mm (Car Body)

3150×1297×1567

Overall dimensions(L*W*H)mm(Van)（Outer size）

1330×1195×295

Overall dimensions(L*W*H)mm(Van)（inner size）

1240x1100x248

Wheel base(mm)

2300

Wheel track(mm)

1094/1094

Min.ground clearance(mm)

150

Lithium battery：Curb weight Kg

609（with battery）/526（without battery）

Van Load(kg)

300

Seating capacity

2

Motor type

AC motor

Kw Rated Power

7.5

Rated Voltage(V)

72

Battery

Maintenance-free lithium battery

Battery capacity

10kw*h

Charger type

Car charger

Charging voltage(V)

220

Range(km) 40km/h

150
